MORANGE - Technical Parameters

Appearance

Black
Specifcations
1. Name

  Specifcations
2. Weight

  136 g
3. Dimensions

  133.2 × 41.4 × 32.6 mm
4. Input

  5 V 2 A Max
5. Operating Temperature

  0°C-40°C
6. Battery Type

  LiPo
7. Charging Time

  1 hour (when using a USB adapter of 5 V 2 A charger)
8. Operating Time

  150 Mins (the value of 1080P 30FPS video recorded in laboratory, just for reference)
Gimbal
1. Angular Vibration Range

  + / - 0.01°
2. Controllable Range

  Pan: -220° to +75°; Roll: ±50°; Roll: ±50°
3. Mechanical Range

  Pan: -240° to +80°; Roll: ±90°; Roll: ±90°
4. Maximum ControllableSpeed

  120°/s
Camera
1. Sensor

  1/2.3 '' CMOS, Effective pixels : 12M
2. Lens

  FOV116° F2.8
3. ISO

  100~3200
4. Electronic Shutter Speed

  1/8000~30s
5. Max Image Size

  4000 × 3000
6. Still Photo Graphy Mode

  Countdown, Long Exposure, Ordinary Mode
7. Max Video Bitrate

  100Mbps
8. Supported File Systems

  FAT32
9. Supported File Systems

  JPEG
10. Supported File Systems

  MOV/MP4(MPEG-4 AVC/H.264)
11. Audio Output

  None
12. Video Resolution

  4K; Ultra HD : 3840 × 2160（24/30/60FPS）
  2K：2560 ×1440 (24/30/60FPS)
  FHD：1920 × 1080 (24/30/60FPS)
13. Video Mode

  Timelapse, Motionlapse, Ordinary Video, SlowMotion
  (Resolution is 1080P60/120/240FPS)
14. Supported SD Card

  It supports a maximum of 256GB.
  It is recommended to use a U3-grade
  Micro SD card whose writing speed
  is stable at no lower than 30MB/s
